Easy Operation

For erasing Hard Drives the operator turns the security key to the “On” position and places the media on the top surface of the degausser. Pressing the red “Power” button turns on the magnetic field and the media is held in place for 3-5 seconds. Pressing the “Power” button turns off the magnetic field. The operator should then rotate the media 90° on the top of the degausser and repeat the process by applying the magnetic field for another 3-5 seconds. The media should then be flipped over and the process repeated making 4 degauss cycles in total. On completion of the fourth cycle , the media will be completely erased.

Service and Support

The SV91M comes with an impressive 36 month back to base, all parts and labor included warranty. Extended warranties also available. We are so confident in our product build quality that whether you opt for an extended warranty or not, our factory-based technical support team are available for free phone and email support. This support extends for the entire lifetime of ownership.

Compliance

NATO Approval
The North Atlantic Treaty Organisation has approved the SV91 for security applications. The NATO stock numbers are as follows:
5836-99-591-3345 (50Hz)
5836-99-500-5299 (60Hz)
Regulatory Compliance
Strict industry standards & government regulations are in place that force organizations to mitigate the risk of unauthorized   exposure of confidential corporate & government data. These regulations include;
HIPAA (Health Insurance Portability & Accountability Act)
GDPR (General Data Protection Regulation)
FACTA (The Fair and Accurate Credit Transactions Act of 2003)
GLB (Gramm-Leach Bliley)
Sarbanes-Oxley Act (SOx)
Payment Card Industry Data Security Standards (PCI DSS)
NSA (National Security Agency)

A two step process has also been set out by the National Security Agency (NSA) and Central Security Service (CSS) for the disposal of magnetic storage devices, including hard drives. They recommend that hard drives are sanitized (erased) with a degausser prior to the physical destruction of the hard drive itself.
It is this standard that all government agencies must adhere to and is now recognized by most organizations as the most effective and fool-proof way of disposing of hard drives effectively and securely.
Security of data is also a legal requirement under the UK’s Data Protection Act 1998, ensuring the complete removal of all data from redundant equipment is essential to maintain the security and integrity of data. In addition, many standards insist that the process of data destruction is fully traceable. Using a degausser to sanitize media provides a fully auditable procedure.

​

Specification.

Degauss Method:

Flatbed Manual Degausser

​

Media Handling:

Standard PC, Laptop and Server 3.5”, 2.5” & 1.8” Hard Drives. Longitudinal & perpendicular recording up to 2TB.

All Backup tapes including DLT,2,3,4,5,6 & SDLT, LTO1,2,3,4,5,6,7 & 8; 3480/3490/3490e, 3590, 9840 & T9940 & T10000 tape; Ultrium & Redwood SD-3 tape & cartridges; Mammoth 1 & 2, 8mm, AIT1 & 2,M2 tape; DDS 1, 2, 3, 4 & 5, DD-2

​

Magnetic Force:

7,000 gauss

​

Cycle Time/Erase Time:

12 seconds typical

​

Throughput:

20 hard drives/ 40 tapes per hour typical

​

Duty Cycle:

Non-Continuous 20%

​

Power Supply:

208-220 VAC, 60Hz; 220-240 VAC, 50Hz
(Specify voltage and frequency when ordering)



Current Rating:

50Hz 10 Amps, 60Hz 12 Amps Typical

​

Controls:

On/Off Power switch, Security key

​

Dimensions (WxHxD):

16.5" x 6" x 10.6" (42cm x 15cm x 27cm)

​

Unit Weight:

57lbs (26kg)

​

Packed Dimensions (WxHxD):

20.8" x 25.5" x 10.6" (53cm x 65cm x 27cm)

​

Packed Weight:

62lbs (28kg)

​

Temperature:

41°F - 104°F (5°C - 40°C)

​

Humidity:

10%H – 40%H Without Condensation

​

Options:

Transportation case

​

Warranty:

36 months back to base, all parts and labor included. Extended warranties also available.

​

Certifications:

NATO Approved, CE

​

Specifications are subject to change without notice

Note: After degaussing, hard drives should not be reused as they are stressed in the erasure process. Some backup tapes may not be reusable after degaussing due to the servo track being erased.
